序号No. | 内容Item | 参数Parameter | 备注Notes |
1 | 容量Capacity | 2800mAh |
|
2 | 放电电流Discharge current | 5mA |
|
3 | 终止电压Cut-off voltage | 1.5V |
|
4 | 开路电压Open-circuit voltage | 3.00~3.40 |
|
5 | 最大连续放电电流 Max. continuous discharge current | 2000mA |
|
6 | 最大脉冲放电电流 Max. pulse current | 4000mA |
|
7 | -20℃放电(5mA/1.5V) -20℃ discharge(20mA/1.5V) | >2400mAh |
|
8 | 工作温度 Operating Temperature | -40℃~70℃ |
|
9 | 贮存温度 Storage Temperature | -20℃~40℃ |
|
10 | 重量Weight | 26g |
|
11 | 尺寸(直径*总高) Dimension(dia *height) | (Φ17.5±0.3)*(49.5±0.5)mm |
|
12 | 储存寿命Shelf life | 10 years |
|
